HUIYA.800LBS.OA STEEL RAISED FLOOR-OFFICE

Cable and wiring management has become increasingly critical as the business environment evolves and office automation grows more complicated and sophisticated. HUIYA.OA600.800LBS network raised floors efficiently and methodically managed cables and cabling, enabling clients to build well-organized, clean, and chaotic working environments. Additionally, environmentally beneficial materials OA office flooring system are lightweight and highly recyclable. The strength, performance, increased usability, and ease of maintenance of the OA access floor indicate its dependability.

huiya office raised floor banner

HUIYA.800LBS.OA STEEL RAISED FLOOR WITH STRINGER-OFFICE
HUIYA.800LBS.OA STEEL RAISED FLOOR are epoxy coated unitized shells consisting of a flat steel top sheet welded to a formed steel bottom sheet filled with a highly controlled mixture of a lightweight cement infill. Manufactured to exacting tolerances, these non-combustible, rigid panels deliver the ultimate in strength, durability, and acoustic performance.
HUIYA.800LBS.OA STEEL RAISED FLOOR has a full range of panels engineered to meet Tate Standards per CISCA testing methods and an extensive selection of understructure supports. For further information on product details, architectural details, system specifications, select the proper panel to meet the needs of your specific application.

OA600 raised floor

SYSTEM NAME:
OA600 RAISED FLOOR 800LBS(0.5/0.6mm)
DESCRIPTION
OA600 RAISED FLOOR 1000LBS is considered the classic system for commercial environments. It is widely used for office building and data cable management.
COMPLIANT STANDARDS
CISCA Recommended Test Procedures for Access Floors (2007)
SIZE 600mm x 600mm
DEPTH 33mm
CORE Cementitious Compound
FINISH
Standard powder coated finish.

Contact Huiya  Email:[email protected]  WhatsApp:+86 18018280738

If Customer need  Pedestal Floor Finish Height(FFH=50mm-300mm), Huiya Raised Floor Factory Recommend Raised Floor Understructure Pedestal Corner Lock System Method.You can Contact Huiya Factory Sale For Further Communication.

Pedestal NameAluminum Cross Head Pedestal (Low Profile Type)
HeightFFH60-300mm
Pedestal Head70(Length)x70(Width)x20mm(height)Aluminum Die Cast
Base Plate80(Length)x80(Width)x1.8mm(thickness)Steel Plate
Threaded Solid RodM16
SurfaceGalvanized Steel
Pedestal GasketBlack Plastic Gasket
Pedestal NameSteel Flat Head Pedestal(Low Profile Type)
Height FFH60-300mm
Pedestal Head70(Length)x70(Width)x3mm(thickness)Steel Plate
Base Plate80(Length)x80(Width)x1.8mm(thickness)Steel Plate
Threaded Solid RodM16
SurfaceGalvanized Steel
